TECHNICAL INFO

LIGHT SOURCE OUTPUT:

5000 lm

FITTING OUTPUT:

3990 lm

INSULATION CLASS:

Class I

POWER SUPPLY:

220-240 Vac 50/60 Hz

COLOUR TEMPERATURE:

4000 K

COLOUR RENDERING INDEX:

CRI ≥ 80

DEGREE OF PROTECTION:

IP65

WEIGHT:

2,3 KG

DIMENSIONS:

1265x130x88 mm

NOMINAL POWER:

36 W

IMPACT RESISTANCE RATING (IK):

IK08

OPERATING TEMPERATURE:

-20°C / +45°C

LED SOCKET:

T8

LED TUBE LENGTH:

1200 mm

MAX. LED POWER:

18 W

DIMENSIONS

REPLACEABLE LED

The two included led tubes of NORMAL can be replaced thanks to the standard T8 socket.

FIXING SYSTEMS

CEILING

SUSPENSION

NORMAL 236

Choose NORMAL, reliability and effectiveness to illuminate your spaces. Contact us for commercial information.
